Cámara IP Industrial 2MP IK3030V Ampliar

IK3030V Cámara IP Industrial 2MP

es un excelente sistema antiexplosivos y cámara de seguridad integrada con iluminadores IR o Laser para visión nocturna hasta 500 metros. Dispositivo realizado con acero inoxidable garantizando alta resistencia a la corrosión derivada de los agentes químicos.

Más detalles

IK3030V


Indicarme cuando esté disponible
  •  2Mp progressive CCD, 20X optical zoom
  • H.264 dual-stream encoding
  • Max 30fps@1080p resolution
  • Explosion proof level: ExdIICT6/DIP A20 TA,T6
  • Electro-polished stainless steel meterial
  • Night vision up to 100m with IR
  • 360° rotation, Pan: 0.05° ~30° /s; Tilt: 0.05° ~30° /s
  • Up to 80 presets, 5 auto scans, 8 cruising tracks
  • IP67 waterproof
Model HDS3032V
Explosion Proof
Ex-Proof LevelExdIICT6/DIP A20 TA,T6
Enclosure MaterialStainless steel 316L
Window MaterialToughened glass with double-side Nano coating
Surface PolishmentElectro-polished
Protection LevelIP68
Camera  IK3030V
Image Sensor1/2.8" CMOS
Effective Pixels1920(H) x 1080(V), 2.0 Megapixels
Scanning SystemProgressive
Electronic Shutter Speed1/6 s ~ 1/8000 s
Min. Illumination
  • Color: 0.03 lux (F1.6, 50IRE)
  • B/W: 0.01 lux (F1.6, 50IRE)
S/N RatioMore than 50dB
Camera Features
Day/NightAuto(ICR) / Color / B/W
Wide Dynamic Range /
Backlight CompensationON/OFF
White BalanceAuto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual
Gain ControlAuto/Manual/Max
Noise Reduction3D DNR
Privacy MaskingUp to 8 areas
Zoom22x optical
Lens
Focal Length4.7 ~ 103.4 mm
Max ApertureF1.6 ~ F3.2
Focus ControlAuto / Manual
Angle of ViewH: 55.4° ~ 2.9°
PTZ
Night Vision Range100m with IR LED
Angle Return Support with Pelco D, default enquiry return
Angle ControlSupport
Pan Rotation Range0° ~ 360° continuous
Tilt Rotation Range -90° ~ +90°
Rotation Speed Pan 0.05° ~30° /s; tilt 0.05° ~30° /s
Preset80
Auto Scan5, based on OSD menu
Cruising Track8, each with 80 presets postions
Patter Tour1
Guard LocationCall preset, cruising track,  atuo scan or pattern tour  if there is no command in a period of time
Motion ScheduleCall preset, auto scan, cruising track or pattern tour by preset schedule
Wiper ControlSupport
Video
CompressionH.264/MJPEG
Resolution1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240)
Frame RateMain stream: 1080P/720P(1 ~ 25/30fps)
Substream:D1/CIF(1 ~ 25/30fps)
Bit Rate1Mbps~10Mbps
Network
EthernetRJ-45 (10/100Base-T)
ProtocolTCP/IP,HTTP,DHCP,DNS,RTP/RTCP,PPPoE, DDNS
ONVIFONVIF Ver. 2.2
User AccessMinimum 5 users
General
Power SupplyAC 24V ±25%
Power Consumption100W
Working EnvironmentWorking temperature: -30ºC ~ 60ºC
Working humidity:90% RH (No condensing, no heating)
Dimensions498(L) x 310(W)x377.5(H) mm
Weight35kgs
