Cámara tipo Box Full HD IKN1202HD Ampliar

IKN1202HD Cámara tipo Box Full HD

Cámara IP Box de interior H.264 Full HD IKN1202HD- Video Analytics Incluido, Filtro de Corte IR Extraíble

Más detalles

  • H.264 Full Frame en HD1080p
  • Compresión de vídeo: H.264, MJPEG
  • Dual Stream
  • Calidad de imagen Ultra
  • Audio bidireccional con G.711
  • vídeo Detección de movimiento Soporte
  • Soporte de memoria microSD
  • Apoyo Integral SDK
  • integrado Análisis de vídeo
  • Compatibilidad con ONVIF



Specifications
Camera Module
Image Sensor1/2.7" 1080p CMOS
Effective Pixels1920 x 1080
Scanning SystemProgressive Scan
AGC ControlAuto
Minimum IlluminationColor : 0.5 lux, BW : 0.001 lux(Sens-up 32X)
LensC/CS Mount lens, Optional
Day&NightIR Cut Filter Removal
Smart Edge EnhanceSupported (Auto adjust the sharpness by Lux)
2D-DNRSupported (1 ~ 16)
DSS(Sens-up)2X ~ 16X
White BalanceATW/Manual/Push
BLCOn(possible to designate zone)/Off
IrisLens optional (DC Auto iris)
Video
Compression FormatH.264, MJPEG
Number of StreamsDual Stream, Configurable
Resolution1920x1080, 1280x720, 800x450
480x270, 320x180
Compression FPSUp to 30@HD1080
Image OrientationFlip / Mirror / Corridor Mode(-90°,+90°)
Motion DetectionBuilt-in
Burnt-in TextVideo stream overlay text
Analog Output1ch composite video for installation only
Audio
Input1 channel
Output1 channel
Compression FormatG.711
Function
Digital Input1
Digital Output1
Network10/100 Base-T
ProtocolHTTP, QoS Layer 3 DiffServ, TCP/IP, UDP/IP, RTSP, RTCP, RTP/UDP, RTP/TCP, mDNS, UPnP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2c/v3(MIB-II), IGMP, ICMP
USB 2.01 (A Plug, Local storage)
SD Memory Card SlotBuilt-in SD slot(SD card not included)
(Recommend Class 4 and higher for HD recordings)
Electrical
Power Source12V DC
Power over EthernetSupport (IEEE 802.3af)
Power Consumption (Approx)350 mA @ 12V DC
Environmental
Fan/HeterNone
Operating TemperatureOperating Range
- DC12V: 0 °C~ 50 °C (32 °F ~ 122 °F)
- PoE: 0 °C ~ 50 °C (32 °F ~ 122 °F)
Operating HumidityUp to 85% RH (Non-condensing)
Mechanical
MaterialAluminum Die-Casting
ColorCool Gray
Dimension71(W) x 64(H) x 140(D) mm
Weight (Approx)500g
Video Content Analysis (Included as Standard)
High PerformanceAdvanced Tracking Algorithm, Low False Alarm Rate
Easy to UseIntuitive Web Browser Interface
Detection ZonesMulti-segment Polygons and Lines
On-screen DisplayReal-time Display of Tracking Data and Events
Tamper DetectionDetect camera tampering
Video Content Analysis (Option)
Detection BehaviorDirection, Stopping, Dwell, Entering, Exiting, Appear and Disappear Filters, Abandoned/Removed Object Detection, Tailgating Detection
3D BehaviorPerspective Corrected Size and Speed Filters
CountingCounting Functions
Meta DataPlain XML Format
Tracking PeopleTracking individuals separately among overlapped multiple people
Color Filter10 colors in total ; Distinguish objects by color
