IKE3500M-5111 Cámara con Analitica de Video

Megapixel high quality and performance H.264 compression networking camera.

Más detalles

Más

H.264, hasta 1600 x 1200
Compresión de video: H.264, MPEG-4, MJPEG
doble secuencia
Embebidos Análisis Inteligente de Video
Texto Quemado-in, soporte de video de detección de movimiento
Audio bidireccional
Soporte de memoria microSD
Apoyo IP66
Actualización de firmware remota por la red
SDK Apoyo Integral

Specifications
Camera Module
Image Sensor	Aptina (Micron) 1/3.2" (4:3) CMOS 2M
Effective Pixels	1600 x 1200 (UXGA, 2M)
Scanning System	Progressive Scan
Dynamic Range	71dB
SNR	Max 42.3dB
Minimum Illumination	0.5 Lux(50IRE), 0.1 Lux(DSS x5 ON)
Lens	3.3~12 mm F1.6 Fixed Iris
Day & Night	S/W
Video
Megapixel Compression	H.264, MJPEG
Number of Streams	Dual Stream, Configurable
Resolution	UXGA, SXGA, HD720, XGA, D1, 4CIF, 2CIF, VGA, CIF, QVGA, QCIF (See Manuals for Detail Information)
Compression FPS (In case of VCA or Burnt In Annotation on, fps could be decreased)	H.264 5 fps@UXGA (1600 x 1200) 8 fps@SXGA (1280 x 1024) 12 fps@HD720 (1280 x 720) 15 fps@XGA (1024 x 768), D1 (720 x 480) MPEG-4 15 fps@D1 (720 x 480) MJPEG 15 fps@UXGA (1600 x 1200)
Motion Detection	Built-in (DSP)
Burnt-in Text	Video stream overlay text (DSP)
Audio
Input	1 channel
Output	1 channel
Compression Format	G.711
Function
Digital Input	1
Digital Output	1
Serial port	RS485
Network	10 / 100 Base-T
Protocol	TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, SNTP, mDNS, UPnP, SMTP, SOCK, IGMP, DHCP, DDNS, SSL v2/v3, IEEE 802.1X, SSH, SNMP v2/v3
SD Memory Card Slot	Optional, microSD up to 8GB
Electrical
Power Source	12V DC
Power over Ethernet	Support, IEEE 802.3af
Power Consumption (Approx)	270 mA @ 12V DC
Environmental
Operating Temperature	-10 °C ~ °50 C (14 °F ~ 122 °F)
Operating Humidity	Up to 85% RH, Non-condensing
Mechanical
Material	Aluminum Die Casting / Polycarbonate
Color	Ivory
Dimension	Housing: 150(ø) x 113(H) mm, Dome: 100(ø) mm
Weight (Approx)	1,080 g
Primary Intelligent Video Analytics (Included as Standard)
High Performance	Advanced Tracking Algorithm, Low False Alarm Rate
Easy to Use	Intuitive Web Browser Interface
Detection Zones	Multi-segment Polygons and Lines
On-screen Display	Real-time Display of Tracking Data and Events
Camera Shake Cancellation	Improve the VCA performance with cameras that are prone to shake
Tamper Detection	Detect camera tampering
Advanced Intelligent Video Analytics (Option)
Detection Behavior	Direction, Stopping, Loitering, Entering, Exiting, Appear, and Disappear Filters, Abandoned/Removed Object Detection, Tailgating Detection
3D Behavior	Perspective Corrected Size and Speed Filters
Statistics	Counting Functions and Other Statistics
Meta Data	Plain XML Format
